In image processing, a steerable filter is an orientation-selective filter that can be computationally rotated to any direction. Rather than designing a new filter for each orientation, a steerable filter is synthesized from a linear combination of a small, fixed set of "basis filters". This approach is efficient and is widely used for tasks that involve directionality, such as edge detection, texture analysis, and shape-from-shading. The principle of steerability has been generalized in deep learning to create equivariant neural networks, which can recognize features in data regardless of their orientation or position. == Example == A common example of a steerable filter is the first derivative of a two-dimensional Gaussian function. This filter responds strongly to oriented image features like edges. It is constructed from two basis filters: the partial derivative of the Gaussian with respect to the horizontal direction ( x {\displaystyle x} ) and the vertical direction ( y {\displaystyle y} ). If G ( x , y ) {\displaystyle G(x,y)} is the Gaussian function, and G x {\displaystyle G_{x}} and G y {\displaystyle G_{y}} are its partial derivatives (which measure the rate of change in the x {\displaystyle x} and y {\displaystyle y} directions, respectively), a new filter G θ {\displaystyle G_{\theta }} oriented at an angle θ {\displaystyle \theta } can be synthesized with the formula: G θ = cos ( θ ) G x + sin ( θ ) G y {\displaystyle G_{\theta }=\cos(\theta )G_{x}+\sin(\theta )G_{y}} Here, the basis filters G x {\displaystyle G_{x}} and G y {\displaystyle G_{y}} are weighted by cos ( θ ) {\displaystyle \cos(\theta )} and sin ( θ ) {\displaystyle \sin(\theta )} to "steer" the filter's sensitivity to the desired orientation. This is equivalent to taking the dot product of the direction vector ( cos θ , sin θ ) {\displaystyle (\cos \theta ,\sin \theta )} with the filter's gradient, ( G x , G y ) {\displaystyle (G_{x},G_{y})} . == Generalization in deep learning: Equivariant neural networks == The concept of steerability is foundational to equivariant neural networks, a class of models in deep learning designed to understand symmetries in data. A network is considered equivariant to a transformation (like a rotation) if transforming the input and then passing it through the network produces the same result as passing the input through the network first and then transforming the output. Formally, for a transformation T {\displaystyle T} and a network f {\displaystyle f} , this property is defined as f ( T ( input ) ) = T ( f ( input ) ) {\displaystyle f(T({\text{input}}))=T(f({\text{input}}))} . This built-in understanding of geometry makes models more data-efficient. For example, a network equivariant to rotation does not need to be shown an object in multiple orientations to learn to recognize it; it inherently understands that a rotated object is still the same object. This leads to better generalization and performance, particularly in scientific applications. === Mathematical foundation === Equivariant neural networks use principles from group theory to create operations that respect geometric symmetries, such as the SO(3) group for 3D rotations or the E(3) group for rotations and translations. Instead of learning standard filter kernels, these networks learn how to combine a fixed set of basis kernels. These basis functions are chosen so that they have well-defined behaviors under transformation groups. Spherical harmonics are frequently used as basis functions because they form a complete set of functions that behave predictably under rotation, making them ideal for creating steerable 3D kernels. Features within the network are treated as geometric tensors, which are mathematical objects (like scalars or vectors) that are "typed" by their behavior under transformations. These types correspond to the irreducible representations (irreps) of the group. The tensor product is the fundamental operation used to combine these typed features in a way that preserves equivariance, guaranteeing that the network as a whole respects the desired symmetry. Frameworks like e3nn simplify the construction of these networks by automating the complex mathematics of irreducible representations and tensor products. === Applications === Steerable and equivariant models are highly effective for problems with inherent geometric symmetries. Examples include: Protein structure analysis: SE(3)-equivariant networks can process 3D molecular structures while respecting their rotational and translational symmetries. 3D Point cloud processing: Rotation-equivariant filters built from steerable spherical functions can perform tasks like 3D shape classification. Computational chemistry: E(3)-equivariant graph neural networks are used to model interatomic potentials for molecular dynamics simulations, creating highly accurate and data-efficient models of physical systems.
The 2028 Global Intelligence Crisis
The 2028 Global Intelligence Crisis is a report authored by James van Geelen and Alap Shah and published by Citrini Research in February 2026, on the impact of artificial intelligence on humanity's future. Written in the form of a scenario analysis, it was viewed millions of times online and reportedly caused a fall in the stock market prices of major tech and financial firms. It also received criticism among others, for its allegedly flawed economic logic. The 'thought exercise', as the authors called it, painted a gloomy picture for the near future, where outputs keep growing while consumer's ability to spend collapses. "...driven by ai agents that don’t sleep, take sick days or require health insurance”, "outputs that are shown in national accounts increases, "but never circulates through the real economy"(which the report calls 'Ghost GDP'), the authors argued. In other words, the authors predict a scenario where the owners of the AI firms will accumulate a vast fortune but there will be scant demand from consumers as AI would cause massive unemployment. The authors caution the reader that what they make is a scenario and not a prediction. In the scenario they visualise, any service whose value proposition is “I will navigate complexity that you find tedious” is getting disrupted. The reports argues that the unique ability of human beings to analyse, decide, create, persuade, and coordinate was “the thing that could not be replicated at scale,” and call the historical scarcity of this precious entity 'friction'. When this friction becomes zero, a gamut of changes occur which then triggers a cascading of changes across the economy. ”Travel booking platforms are an early casualty; Financial advice. tax prep., and routine legal work follow suit. National unemployment rate go as high 10.2% and the S&P 500 goes for a massive 38% peak-to-trough crash. In contrast to the previous technological revolutions the high-earning professionals suffers more and get forced to take up roles in the gig economy. Labour supply becomes abundant and this cuts wages all across the economy. The dent in income for the employees then affects other sectors of the economy such as the residential mortgage market. The losses for the software companies triggers loan defaults and heralds peril for the private credit sector.
Common-mode signal
In electrical engineering, a common-mode signal is the identical component of voltage present at both input terminals of an electrical device. In telecommunication, the common-mode signal on a transmission line is also known as longitudinal voltage. Common-mode interference (CMI) is a type of common-mode signal. Common-mode interference is interference that appears on both signal leads, or coherent interference that affects two or more elements of a network. In most electrical circuits, desired signals are transferred by a differential voltage between two conductors. If the voltages on these conductors are U1 and U2, the common-mode signal is the average of the voltages: U cm = U 1 + U 2 2 {\displaystyle U_{\text{cm}}={\frac {U_{1}+U_{2}}{2}}} When referenced to the local common or ground, a common-mode signal appears on both lines of a two-wire cable, in phase and with equal amplitudes. Technically, a common-mode voltage is one-half the vector sum of the voltages from each conductor of a balanced circuit to local ground or common. Such signals can arise from one or more of the following sources: Radiated signals coupled equally to both lines, An offset from signal common created in the driver circuit, or A ground differential between the transmitting and receiving locations. Noise induced into a cable, or transmitted from a cable, usually occurs in the common mode, as the same signal tends to be picked up by both conductors in a two-wire cable. Likewise, RF noise transmitted from a cable tends to emanate from both conductors. Elimination of common-mode signals on cables entering or leaving electronic equipment is important to ensure electromagnetic compatibility. Unless the intention is to transmit or receive radio signals, an electronic designer generally designs electronic circuits to minimise or eliminate common-mode effects. == Methods of eliminating common-mode signals == Differential amplifiers or receivers that respond only to voltage differences, e.g. those between the wires that constitute a pair. This method is particularly suited for instrumentation where signals are transmitted through DC bias. For sensors with very high output impedance that require very high common-mode rejection ratio, a differential amplifier is combined with input buffers to form an instrumentation amplifier. An inductor where a pair of signaling wires follow the same path through the inductor, e.g. in a bifilar winding configuration such as used in Ethernet magnetics. Useful for AC and DC signals, but will filter only higher frequency common-mode signals. A transformer, which is useful for AC signals only, and will filter any form of common-mode noise, but may be used in combination with a bifilar wound coil to eliminate capacitive coupling of higher frequency common-mode signals across the transformer. Used in twisted pair Ethernet. Common-mode filtering may also be used to prevent egress of noise for electromagnetic compatibility purposes: High frequency common-mode signals (e.g., RF noise from a computing circuit) may be blocked using a ferrite bead clamped to the outside of a cable. These are often observable on laptop computer power supplies near the jack socket, and good quality mouse or printer USB cables and HDMI cables. Switch mode power supplies include common and differential mode filtering inductors to block the switching signal noise returning into mains wiring. Common-mode rejection ratio is a measure of how well a circuit eliminates common-mode interference.
Digital signal
A digital signal is a signal that represents data as a sequence of discrete values; at any given time it can only take on, at most, one of a finite number of values. This contrasts with an analog signal, which represents continuous values; at any given time it represents a real number within an infinite set of values. Simple digital signals represent information in discrete bands of levels. All levels within a band of values represent the same information state. In most digital circuits, the signal can have two possible valid values; this is called a binary signal or logic signal. They are represented by two voltage bands: one near a reference value (typically termed as ground or zero volts), and the other a value near the supply voltage. These correspond to the two values zero and one (or false and true) of the Boolean domain, so at any given time a binary signal represents one binary digit (bit). Because of this discretization, relatively small changes to the signal levels do not leave the discrete envelope, and as a result are ignored by signal state sensing circuitry. As a result, digital signals have noise immunity; electronic noise, provided it is not too great, will not affect digital circuits, whereas noise always degrades the operation of analog signals to some degree. Digital signals having more than two states are occasionally used; circuitry using such signals is called multivalued logic. For example, signals that can assume three possible states are called three-valued logic. In a digital signal, the physical quantity representing the information may be a variable electric current or voltage, the intensity, phase or polarization of an optical or other electromagnetic field, acoustic pressure, the magnetization of a magnetic storage media, etcetera. Digital signals are used in all digital electronics, notably computing equipment and data transmission. == Definitions == The term digital signal has related definitions in different contexts. === In digital electronics === In digital electronics, a digital signal is a pulse amplitude modulated signal, i.e., a sequence of fixed-width electrical pulses or light pulses, each occupying one of a discrete number of levels of amplitude. A special case is a logic signal or a binary signal, which varies between a low and a high signal level. The pulse trains in digital circuits are typically generated by metal–oxide–semiconductor field-effect transistor (MOSFET) devices, due to their rapid on–off electronic switching speed and large-scale integration (LSI) capability. In contrast, bipolar junction transistors more slowly generate signals resembling sine waves. === In signal processing === In digital signal processing, a digital signal is a representation of a physical signal that is sampled and quantized. A digital signal is an abstraction that is discrete in time and amplitude. The signal's value only exists at regular time intervals, since only the values of the corresponding physical signal at those sampled moments are significant for further digital processing. The digital signal is a sequence of codes drawn from a finite set of values. The digital signal may be stored, processed or transmitted physically as a pulse-code modulation (PCM) signal. === In communications === In digital communications, a digital signal is a continuous-time physical signal, alternating between a discrete number of waveforms, representing a bitstream. The shape of the waveform depends on the transmission scheme, which may be either a line coding scheme allowing baseband transmission; or a digital modulation scheme, allowing passband transmission over long wires or over a limited radio frequency band. Such a carrier-modulated sine wave is considered a digital signal in literature on digital communications and data transmission, but considered as a bit stream converted to an analog signal in specific cases where the signal will be carried over a system meant for analog communication, such as an analog telephone line. In communications, sources of interference are usually present, and noise is frequently a significant problem. The effects of interference are typically minimized by filtering off interfering signals as much as possible and by using data redundancy. The main advantages of digital signals for communications are often considered to be noise immunity, and the ability, in many cases such as with audio and video data, to use data compression to greatly decrease the bandwidth that is required on the communication media. == Logic voltage levels == A waveform that switches representing the two states of a Boolean value (0 and 1, or low and high, or false and true) is referred to as a digital signal or logic signal or binary signal when it is interpreted in terms of only two possible digits. The two states are usually represented by some measurement of an electrical property: Voltage is the most common, but current is used in some logic families. Two ranges of voltages are typically defined for each logic family, which are frequently not directly adjacent. The signal is low when in the low range and high when in the high range, and in between the two ranges the behavior can vary between different types of gates. The clock signal is a special digital signal that is used to synchronize many digital circuits. The image shown can be considered the waveform of a clock signal. Logic changes are triggered either by the rising edge or the falling edge. The rising edge is the transition from a low voltage (level 1 in the diagram) to a high voltage (level 2). The falling edge is the transition from a high voltage to a low one. Although in a highly simplified and idealized model of a digital circuit, we may wish for these transitions to occur instantaneously, no real-world circuit is purely resistive, and therefore no circuit can instantly change voltage levels. This means that during a short, finite transition time, the output may not properly reflect the input, and will not correspond to either a logically high or low voltage. == Modulation == To create a digital signal, a signal must be modulated with a control signal to produce it. The simplest modulation, a type of unipolar encoding, is simply to switch on and off a DC signal so that high voltages represent a '1' and low voltages are '0'. In digital radio schemes, one or more carrier waves are amplitude, frequency or phase modulated by the control signal to produce a digital signal suitable for transmission. Asymmetric Digital Subscriber Line (ADSL) over telephone wires, does not primarily use binary logic; the digital signals for individual carriers are modulated with different-valued logics, depending on the Shannon capacity of the individual channel. == Clocking == Digital signals may be sampled by a clock signal at regular intervals by passing the signal through a flip-flop. When this is done, the input is measured at the clock edge and the signal from that time. The signal is then held steady until the next clock. This process is the basis of synchronous logic. Asynchronous logic also exists, which uses no single clock, and generally operates more quickly, and may use less power, but is significantly harder to design.
Feature detection (web development)
Feature detection (also feature testing) is a technique used in web development for handling differences between runtime environments (typically web browsers or user agents), by programmatically testing for clues that the environment may or may not offer certain functionality. This information is then used to make the application adapt in some way to suit the environment: to make use of certain APIs, or tailor for a better user experience. Its proponents claim it is more reliable and future-proof than other techniques like user agent sniffing and browser-specific CSS hacks. == Techniques == A feature test can take many forms. It is essentially any snippet of code which gives some level of confidence that a required feature is indeed supported. However, in contrast to other techniques, feature detection usually focuses on performing actions which directly relate to the feature to be detected, rather than heuristics. === JavaScript === JavaScript feature detection can inspect the DOM and the local JavaScript environment to test whether browser features or APIs are supported. The simplest technique is to check for the existence of a relevant object or property. For example, the Geolocation API (used for accessing the device's knowledge of its geographical location, possibly obtained from a GPS navigation device) exposes a geolocation property on the navigator object in the DOM; the presence of which implies the Geolocation API is supported: if ('geolocation' in navigator) { // Geolocation API is supported } For a higher level of confidence, some feature tests will attempt to invoke the feature then look for clues that it behaved properly. For example, a test for support for cookies might attempt to set a value as a cookie and then verify it can be read back. === CSS === In CSS, the at-rule @supports introduced in 2015 allows to test if a given feature is supported. For instance the following code activates the declarations only if the user agent supports display: flex: == Undetectables == Some browser features are considered undetectable, because no clues are known to give sufficient confidence that a feature is supported. These are often because of limited information available to the JavaScript environment in the browser; generally features must be exposed via the DOM in some way in order to be detectable using JavaScript. When undetectables are encountered, it is common to turn to user agent sniffing as an alternative mechanism, or to employ defensive coding to minimise the impact if the feature turns out not to be supported. The Modernizr project maintains a record of known undetectables on their wiki.
Camfecting
In computer security, camfecting is the process of attempting to hack into a person's webcam and activate it without the webcam owner's permission. The remotely activated webcam can be used to watch anything within the webcam's field of vision, sometimes including the webcam owner themselves. Camfecting is most often carried out by infecting the victim's computer with a virus that can provide the hacker access to their webcam. This attack is specifically targeted at the victim's webcam, and hence the name camfecting, a portmanteau of the words camera and infecting. Typically, a webcam hacker or a camfecter sends his victim an innocent-looking application which has a hidden Trojan software through which the camfecter can control the victim's webcam. The camfecter virus installs itself silently when the victim runs the original application. Once installed, the camfecter can turn on the webcam and capture pictures/videos. The camfecter software works just like the original webcam software present in the victim computer, the only difference being that the camfecter controls the software instead of the webcam's owner. == Notable cases == Marcus Thomas, former assistant director of the FBI's Operational Technology Division in Quantico, said in a 2013 story in The Washington Post that the FBI had been able to covertly activate a computer's camera—without triggering the light that lets users know it is recording—for several years. In November 2013, American teenager Jared James Abrahams pleaded guilty to hacking over 100-150 women and installing the highly invasive malware Blackshades on their computers in order to obtain nude images and videos of them. One of his victims was Miss Teen USA 2013 Cassidy Wolf. Researchers from Johns Hopkins University have shown how to covertly capture images from the iSight camera on MacBook and iMac models released before 2008, by reprogramming the microcontroller's firmware. == Prevention == A computer that does not have an up-to-date webcam software or any anti-virus (or firewall) software installed and operational may be at increased risk for camfecting from different types of malware. Softcams may nominally increase this risk, if not maintained or configured properly. Although a person cannot protect themselves from zero-day exploits that could potentially activate a camera unknowingly, such as Pegasus is able to do on smartphones. The only way to truly avoid being watched through your own camera is by blocking it physically, since software blocks can be overriden by advanced persistent threats. A simple piece of tape is more commonly used to offuscate the feed of the camera. With even Mark Zuckerberg doing so on his personal laptop that appeared during a presentation. And it being the way Snowden, an ex-contractor for the NSA, is portrayed to do so to prevent camfecting in the biopic Snowden. There is now a market for the manufacture and sale of sliding lens covers that allow users to physically block their computer's camera and, in some cases, microphone. A number of phone and laptop manufacturers tried to implement pop-up cameras that can only be opened manually by the user. But the trend did not become mainstream because of the engineering it took to keep the mechanisms up to date, aswell as the fragility and durability of the cameras.
DiscoVision
DiscoVision is the name of several things related to the video LaserDisc format. It was the original name of the "Reflective Optical Videodisc System" format later known as "LaserVision" or LaserDisc. == Description == MCA DiscoVision, Inc. was a division of entertainment giant MCA (Music Corporation of America), established in 1969 to develop and sell an optical videodisc system. MCA released discs pressed in Carson and Costa Mesa, California on the DiscoVision label from the format's Atlanta, Georgia launch in 1978 to 1982 and the release of the film The Four Seasons. DiscoVision titles included films from Universal Pictures, Paramount Pictures, Warner Bros. Pictures, and Disney content. Agreements were made with Columbia Pictures and United Artists, though no discs were released on the DiscoVision label from either studio. Most of these companies later established their own labels for the format, the first being Paramount with a dozen movies released on the Paramount Home Video label in the summer of 1981. The successor to MCA DiscoVision, DiscoVision Associates (DVA), was the result of a partnership between IBM and MCA. It was hoped that the merger would provide the basis for improvement of the quality of DiscoVision pressings, but no appreciable improvement ever took hold. In 1981, responsibility for the laser videodisc was sold to Pioneer Electronic Corporation, after MCA Discovision had previously started a partnership in 1977 with Pioneer, Universal Pioneer, to produce the Pioneer PR-7820 player (the first industrial model of DiscoVision player from 1978), as well as establishing disc pressing plants in Japan. As part of the partnership, Pioneer, in association with MCA, had a disc replication facility in Kofu, Japan that produced discs. Some of the last DiscoVision label discs were manufactured by Pioneer in Japan. In the same year, MCA discontinued their DiscoVision branding, due to the sale of the technology to Pioneer (who then rebranded the format as LaserDisc) and in turn rebranded their laserdisc releases, now fabricated by Pioneer, under the MCA Videodisc banner; this was changed to the "MCA Home Video" name for both its VHS and videodisc releases. Some of DiscoVision's technical staff went on to form MCA Video Games, in an effort to produce video game cartridges. DiscoVision Associates later evolved into a patent holding company which manages and licenses intellectual property related to LaserDisc, Compact Disc, and optical disc technologies, as well as other non-disc related fields. In 1989, Pioneer acquired DiscoVision Associates where it continues to license its technologies independently. As the portfolio of patent expired, the presence of DiscoVision became less visible. However, it established the success of a patent holding company, which other companies are stimulated to generate royalty income from their own patent portfolio.
